Cast Iron Electrodes
AWS/ASME Class Est
SPECIFICATION SFA 5.15
VJ CAST low heat input electrode for welding cast iron where machinabilty is not prime consideration. The electrode should be preferred when a strong and rigid joints is to be obtained between two cast iron parts and also suitable for joining difficults to weld cast iron.joining cast iron to carbon or low alloy steel for reclamation and repair of foundry defects, damaged or cracked casting.Also suitable for welding rusty, corroded,dirty,greasy and oil soaked casting.
Chemical Composition
C 1.60% max
Mn1.20% max
Si 0.60% max
S 0.03% max
Cu 0.80% max
Fe Rem
AWS/ASME ClassENiFe-Cl
SPECIFICATIONSFA 5.15
VJ CAST FeNi is a low heat input electrode ideal for welding cast iron and nickel-copper alloys, offering a strong, ductile, and easily machinable weld deposit. It is suitable for repairing grey and nodular cast iron, filling cavities, rebuilding worn surfaces, and welding Monel to itself or to stainless and carbon steels. Typical applications include the repair of gear teeth, pump impellers, housings, compressors, valves, and gearboxes.
Chemical Composition
C 1.50% max
Mn1.00%
Si 0.70%
Ni 46.00% max
Cr0.04%
Fe Rem%
VJ CAST Ni
AWS E NI-CI
A medium coated pure Nickel type electrode. Theelectrode displays a smooth and stable arcThe electrode produces crack-free machinable welds on cast irons. For joining of cast iron to kild steel, repairing of damaged casting, foundry castings etc.
Mechanical Properties
Hardness 180 BHN max
Chemical Composition
C 1.0-2.0%
Mn 0.5% max
Ni 94-96%
Fe 2-4%
